Description
DIMENSIONS: 130 x 157 x 118 cm
WEIGHT: 142 kg
LOADING CAPACITY: 310 mm support brackets for 6 Bodytone discs of 20 kg per arm (up to 240 kg for training).
USER HEIGHT: Our machines are designed for a very broad spectrum of users, allowing the regulation of them to adapt to different user statures, from 150 to 200 cm approximately.
STRUCTURE: 110×52 mm Steel pipe, 3 mm thick as per UNE EN 10219, quality s-275-J0H. Enriched and optimized to maintain a constant section in the bending process, avoiding fragile areas with low breakage rate. Cold bending process by 4-roller system to avoid deformation during the process, keeping its physical characteristics throughout the piece.
PAINTING PROCESS: 3 layers of paint. Steel pickling and stabilized by immersion of the parts in different degreasing solutions to ensure a perfect and complete cleaning of the base material. Antioxidant primer to ensure adquate isolation of internal oxidation and good paint adhesion. 2 final coats of epoxy paint.
DESIGN PROCESS: Ergonomic and biomechanical study under our associated professional athletes. After a long design process; from the drawing of the sketch, prototypes making and tested by athletes our products are released to the market.
WELDING”: Perimeter closing welding in structural points and union plates.
ASSEMBLY PROCESSES: 10 mm plate-against Plate system, to avoid looseness and torsion in maximum effort areas. Ergonomic and biomechanical research optimized for every exercise.
AXLES: 10 mm thickness plates cut by laser with another 10 mm plate for reinforcement,for a smooth movement withour looseness or torsion produced for the continouos usage or loading.
BEARINGS: SFK double tapared roller bearing, allocated in closed bushing ensuring a constant direction movement.
SEAT AND BACK: Leather simile perspiration resistant, antibacterial and antiallergenic. Back pad,seat pad and rolls in foam 80 kg/m3 density that provides an optimum support for your training and a uniform contact. Resistant to deformation.
GRIPS: Anodized Aluminium, knurled for better grip.
ADJUSTMENTS: Chromed seat post adjustable with 8 laser numbered positions.
OTHERS: Plate supports made in burnished steel, providing more stability to the machine. Turned Aluminium endings. Screw hardness 10.9. Regulation system by a single bolt made of techno polymer with 750 shear rate. 4 non-slip rubber bases.
