Description
DIMENSIONS
206 x 342 x 235 cm.
NET WEIGHT
623 kg
STRUCTURE
Carbon steel tube 75×50 cm / 60×60 cm / 50×50
cm and 2.5 mm thick. Welded by robotised
process, free of projections.
BEARINGS
Ultra-quiet ball bearings with smooth sliding,
allowing a more fluid and pleasant running of the
exercise.
PLATE GUIDES
Stainless steel plate guides.
Double hardened chrome plating treatment for a
better sliding.
POLES
Nylon with V-groove. With an internal bearing
internal bearing and silent running.
STEEL CABLES
PVC coated and 5 mm diameter, with smooth and
safe performance.
Breakage rate breakage: 1.000 kg
WEIGHT PLATES
Made up of 8 towers of 90 kg, with 4.5 kg plates.
Ultra silent movement. Protective rubber bumpers
on anti-shock base. Protective PVC bumpers
between anti-shock plates.
WEIGHT SELECTOR
Magnetic, with colour coded plates for intensity level
and safety cord.
ADJUSTMENT LEVERS
In aluminium, quick release, in red for easy location.
PLATE FAIRING
ABS thermoformed fairing 3mm thick, protecting from
possible thickness, protecting from possible accidents.
ADJUSTABLE PULLEY GUIDE
Adjustable in 35 slotted and laser marked positions.
Chromed finish.
ADJUSTABLE PULLEY GRIPS
Lateral grips for the correct support in different
exercises.
ADJUSTABLE PULLEY STATION
Double station with central adjustable pulley, with
double bearing by means of positioner.
Zinc plated finish.
STATION WITH LOW ROWING PULLEY
Double station with low rowing pulley with footrest
and seat.
STATION WITH HIGH PULLEY FOR BACKSTROKE
Double station with low backstroke pulley with seat
and height adjustable rollers.
STATION WITH HIGH TRICEPS PULLEY
Double station with triceps pulley, with lumbar
support for a better exercise position.
HANDLES
One hand grip handlebar (2 pcs), ankle brace (2
pcs) included.
Low rowing handles (2 pcs), dorsal bar (2 pcs) and
triceps rope (2 pcs) included.
MATERIALS AND FINISHES
High quality finishes.
3.5mm thermoplastic ABS end caps.
BASES
Covered in non-slip rubber.
MAINTENANCE AND LUBRICATION
Lubrication of bearings and calibrated steel
guides.
PAINTING PROCESS
3 coats of paint.
Steel pickled and stabilised by total immersion of the
parts in different degreasing solutions to guarantee
a perfect and complete cleaning of the base
material. Anti-rust primer to guarantee adequate
insulation from internal oxidation and good paint
adhesion. 2 final coats of polyester epoxy powder
paint, dried at 240ºC.
DESIGN PROCESS
Biomechanics and ergonomics study under the
supervision of professionals and associated athletes.
After a long period of design; from sketching,
engineering research, prototype production, testing
by professional athletes, our products are launched
on the market
